Pump Head - 77200 L/S EASY-LOAD II Pump Head
[제조사 : MASTERFLEX, U.S.A]

 돌아가기

Easy-Load II Pump Head





[Ordering Information]
Cat. # 제 품 명
77200-50 Easy-Load II Pump Head, CRS rotor 견적요청
77200-60 Easy-Load II Pump Head, SS rotor 견적요청

Peristaltic Pump에 핵심적인 기능을 하는 Pumping Head
부식성 샘플에 견딜수 있는 housing.

  [주요 기능]
  • Flow rate 0.001 ~ 2,900 ml /min
  • Max. rpm: 600
  • Number of rollers: 4
    - reduce pulsation
    - increase pressure performance, stability
  • Multichannel pumping
  • Housing materials
    - Polyphenylene sulfide (PPS): corrosive liquid, vapors
  • Roller / Rotor materials
    - Plated cold-rolled steel (CRS): general-purpose
    - 300-series stainless steel (SS): corrosive fluids





[Head Specification]
  Model 77200-50 77200-60
  Flow Capacity (ml/min) 0.001 ~ 2,900 ml
  Drive Speed (rpm) 600 rpm
  Number of heads accepted 4
  Housing material Polyphenylene sulfide (PPS)
  Rotor material Cold-rolled steel (CRS) Stainless steel (SS)
  Weight 0.9 kg
